2" Domed Concrete Survey Marker (Aluminum)

Prices
$8.74
1 - 24
$7.32
25 - 99
$5.53
100 - 249
$4.70
250 or more
All prices USD
Availability: In Stock
NO CHARGE for stamping 11 or more markers. There is a $35 setup charge for stamping fewer markers.
Qty:
Add To Field Bag

Customize


Please enter the text you would like printed in the text boxes provided below:
Outside Row
Total of 38 characters and spaces.
Centered at 12 o'clock:
Centered at 6 o'clock:
Inside Row
Total of 25 characters and spaces.
Centered at 12 o'clock:
Centered at 6 o'clock:
Please select the center mark for this cap:
Surveying Center Marks
Utility Center Marks

Product Details





Berntsen 2" Aluminum Concrete Survey MarkerBerntsen Made in America productThe "CD" style aluminum concrete marker has a ¾" (19mm) diameter x 2" (50mm) long stem and is notched to hold firmly in concrete or rock. It is available in 2" (50mm) diameter and one-piece orbital formed from solid 6000 series aluminum.

Our aluminum material is versatile and resistant to most environment conditions, however, if the survey markers are intended to be used in high traffic or caustic environments, such as roadways or salty conditions, we highly recommend using bronze survey markers to improve the lifetime of the markers.

The CAPMAG ceramic magnet can be used with these concrete markers to assure easy detection of the mark with a magnetic locator 6 to 12 inches deep, depending on soil conditions.

The CD2DRL countersink drill bit is made specifically to perfectly recess this CD2 concrete marker in existing concrete.

CD2 Concrete Marker Installation Instructions







Specs






Spec Drawing

Videos

Countersink Drill Bit Video for Berntsen Concrete Markers
