30" Stainless Steel Survey Monument (Flared) Sch. 5 with 3.25" Domed Bronze Cap

Prices
$153.36
1 - 10
$137.03
11 - 24
$125.60
25 - 99
$119.62
100 - 249
$112.45
250 or more
All prices USD
Availability: In Stock
NO CHARGE for stamping 11 or more markers. There is a $35 setup charge for stamping fewer markers.
Qty:
Add To Field Bag

Customize


Please enter the text you would like printed in the text boxes provided below:
Outside Row
Total of 46 characters and spaces.
Centered at 12 o'clock:
Centered at 6 o'clock:
Inside Row
Total of 36 characters and spaces.
Centered at 12 o'clock:
Centered at 6 o'clock:
Please select the center mark for this cap:
Surveying Center Marks

Product Details

SS5NBF30 - 30" Stainless Steel Pipe Survey Monument (Flared)

  • Berntsen Made in America logoNearly identical in appearance to the Iron Pipe / Brass Cap Monument
  • Significantly more corrosion resistant in even the most aggressive soil conditions
  • One of the standard survey monuments used by the U.S.D.I. Bureau of Land Management
  • 2" (50mm) Schedule 5 stainless steel alloy 304 pipe
  • Safe-D-Notch design has a 3/16" (5mm) radius on a 3" (76mm) long sheared cut
  • Four split legs flared to form a self-supporting base anchor
  • 3¼" (83mm) diameter silicon bronze survey cap has a domed (convex) surface and is attached to the pipe with a stainless steel rivet
  • A permanent ceramic magnet is mechanically fixed to the underside of the cap

SS5NBF30 Survey Monument Installation Instructions

Government pricing for this product

is available upon request, please contact

Berntsen at 1-800-356-7388

Specs





A = 3 1/4" (83 mm)
B = 2 3/8" (60 mm)
C = 30" (762 mm)
Government pricing for this product
is available upon request, please contact
Berntsen at 1-800-356-7388
